✨ Core Functions and Advantages
1. Multi-stage telescopic lifting structure: Utilizing a multi-section sleeve-type telescopic design, it achieves a wide range of height='auto' rea expansion with a minimal storage height='auto' rea, meeting the equipment erection height='auto' rea requirements of different scenarios while facilitating transportation and storage.
2. Automatic tilting and angle adjustment: Equipped with an intelligent tilting mechanism, it automatically adjusts the pitch and horizontal angles of the antenna/radar according to operational needs, eliminating the need for manual adjustment and significantly improving deployment efficiency and operational accuracy.
3. Stable and reliable load-bearing base: Equipped with a high-strength, heavy-duty base, ensuring overall stability during lifting and operation, adapting to complex outdoor environments, and exhibiting excellent wind and shock resistance.
4. Integrated intelligent control: Supports automated lifting and angle adjustment, enabling remote control and preset attitudes, adapting to the intelligent operation needs of multiple scenarios such as 5G communication, radar detection, and environmental monitoring. • Communications: Emergency communication for 5G base stations, temporary signal coverage, and deployment of communication equipment for mobile command vehicles.
• Security Monitoring: Border radar detection, high-altitude surveillance cameras, and forest fire early warning equipment deployment.
• Surveying and Exploration: Height and angle adjustment of topographic mapping sensors and meteorological monitoring equipment.
• Emergency Rescue: Rapid deployment of temporary communication, lighting, and monitoring equipment at disaster sites.
• Flexible Height: Multi-stage telescopic design enables large-stroke lifting and lowering with a small storage volume.
• Intelligent and Convenient: Automatic flipping and angle adjustment replace manual operation, improving efficiency.
• Stable and Durable: High-strength structural design adapts to harsh outdoor environments.
• Multi-Scenario Adaptability: Compatible with various devices such as 5G antennas and radar, offering strong versatility.
Structure and Functional Breakdown
1. Lifting Pole Main Body: The multi-section telescopic structure is driven by a servo motor to achieve height='auto' rea adjustment, extending from the retracted state (flat position at the bottom) to a height='auto' rea of several meters or even tens of meters.
2. A flat panel antenna unit is installed at the top for wireless signal transmission and reception (common in tactical communications, radar detection, or emergency command networks). 2. Base and Deployment Mechanism
3. 1. The black base is a quick-deployment platform with a locking/support structure, allowing for stable placement on the ground or vehicle-mounted platform, ensuring the antenna mast remains vertically stable after extension.
2. The bottom flat position demonstrates the folded configuration: the mast is laid down, and the antenna separates from or folds away from the mast, facilitating vehicle transport and rapid deployment.
4. Application Scenarios
5. 1. Military Field: Tactical communication base stations, forward reconnaissance nodes, and antennas for temporary command vehicles.
2. Civilian Field: Emergency disaster relief communications, field research, and communication support for temporary events/activities.
3. Core Advantages: Rapid setup/deployment, portability, high stability, enabling rapid establishment of communication links in complex terrain.
✨ Core Features
Modular Design: The antenna, mast, and base are detachable for easy carrying by individual soldiers or small teams.
Adjustable Height: The antenna height='auto' rea can be flexibly adjusted according to communication needs to optimize signal coverage.
• Rapid deployment: Compared to traditional towers, it can be erected and dismantled in minutes, making it suitable for highly mobile tasks.
